Vertical vs Horizontal Antennas: Why They Behave So Differently

Comments · 25

• TE

  @TelecomTraining · 2 months ago · pinned

  📡 Question for everyone:<br><br>Before watching this video, which antenna did you think was &quot;better&quot;—vertical or horizontal?<br><br>Has your opinion changed after seeing how each antenna radiates, how polarization works, and why antenna height makes such a difference?<br><br>I&apos;d love to hear what type of antenna you&apos;re using and what has worked best for you.<br><br>73,<br><br>Trevor Telecom Training

  1

• DO

  @doc145 · 2 months ago (edited)

  I have an end fed off center fed antenna. It fits my space and works well. I’m thinking of putting up a 20m 1/4 wave as a comparison. Absolutely love your channel!!

  1

• WH

  @wherenowhow6037 · 2 months ago

  Excellent video. &nbsp;Thank you Sir. Much appreciated.

  3

• MS

  @mscir · 2 months ago

  Good video, very clear and very important.

• DO

  @donalfinn4205 · 2 months ago

  This channel is a must for anyone in the radio business.👏🇮🇪

• M8

  @M8UAT · 2 months ago

  Imax2000 vertical &nbsp; s5/7 qrm<br>2ele cubical quad horizontal &nbsp; s0 qrm <br>Excellent video my friend, black background helps a lot.<br>73s

• BI

  @bill-2018 · 2 months ago

  I like inverted vee&apos;s. One main support and close to 50 Ω to match the transmitter.<br>I have five in my attic 20m to 10m and one for 60m squashed into my 13&apos; x 25&apos; garden.<br>A long wire (Well, 25&apos;) with inductance on the far end for lower frequencies. My copy of a Joystick.<br>G4GHB.

  1

• JO

  @johnfox2483 · 2 months ago

  The most important part is near the end.

• ZA

  @ZAN_NEKOTAMA · 2 months ago

  真っ黒な背景で、見辛い。

• GR

  @gregor2600 · 2 months ago

  As in your previous videos, you misrepresent RF as DC, and in doing so, you make mistakes.<br>First of all, define a &quot;return path&quot; in an AC circuit. If current flows in both directions, how can there be only one return path?<br>Secondly, you present RF as if it was water shooting out of the transmitter, through the feed line, splitting at the antenna feed point, half going to the left and half to the right, and then shooting out the ends. RF doesn&apos;t work like that. At <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=205">3:25</a>, the current path on the dipole would never look like that. For this half cycle, the blue arrows on the dipole are pointing in the wrong direction. They should point left. On the second half of the cycle, all arrows on the dipole would point right. You make this mistake in several places (<a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=246">4:06</a>, <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=299">4:59</a>. <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=395">6:35</a>, <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=422">7:02</a>, <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=442">7:22</a>, <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=596">9:56</a> and more).<br>At <a href="https://www.youtube.com/watch?v=k9itS9msZWM&amp;t=586">9:46</a> and other places, you show the dipole with signals shooting out the ends. That&apos;s wrong. The signal is broadside to the dipole.<br>Don&apos;t treat RF as if it were DC. It isn&apos;t. It&apos;s AC and that makes a big difference in understanding what&apos;s going on. Show both halves of the RF cycle. By doing so, you will see your mistakes.

  2

• WH

  @WHLS-lz3wk · 2 months ago

  Fantastic YT Channel !!<br>Spot on descriptions and amazing graphics <br>73 de W3HLS<br>~john
