Japan’s Impossible Runway: Building on 1,165 Steel Legs in the Sea

Haneda Runway D: Japan Built a Runway on 1,165 Steel Legs in the Sea Tokyo's Haneda Airport had run out of room. The only place left for a fourth runway was in the sea, and part of that site sat right in the mouth of the Tama River. A solid island would have blocked the river. So Japan built something no major airport had attempted at this scale: a hybrid runway. Two thirds of it stands on reclaimed land. The other third stands on a steel platform of 198 prefabricated jackets, resting on 1,165 steel piles driven up to 90 m deep, so the river and tides can keep flowing underneath. In this documentary we cover: Why Haneda needed a fourth runway, and why the river mouth made it so hard How engineers strengthened soft clay and reclaimed about 52 million m³ of land How 198 steel jackets were placed onto 1,165 piles with about 5 cm accuracy Building next to live runways under strict height limits, around the clock Stainless steel, titanium and electrical corrosion protection for a 100-year design life The joint between the sinking land half and the fixed pier half How Runway D brought international flights back to central Tokyo Do you think Runway D will make it to 100 years? Let us know in the comments. REFERENCES 1. Construction of D-Runway at Tokyo International Airport – Japanese Geotechnical Society Special Publication (J-STAGE) https://www.jstage.jst.go.jp/article/... 2. HANEDA D-Runway Report No.10: Steel Jacket & Weld (Feb 2010) – MLIT Kanto Regional Development Bureau https://www.pa.ktr.mlit.go.jp/haneda/... 3. Construction of new runway from pier-type jacket structures with large-diameter long steel pipe piles – Soils and Foundations (ScienceDirect) https://www.sciencedirect.com/science... 4. Site-Investigation and Geotechnical Design of D-Runway Construction in Tokyo Haneda Airport – Soils and Foundations (ScienceDirect) https://www.sciencedirect.com/science... 5. Jacket Method Technology for Haneda Airport D-Runway – Nippon Steel Engineering Technical Report, Vol. 01 (2010, Japanese) https://www.eng.nipponsteel.com/files... 6. Non-Ferrous Structural Materials (Titanium, Aluminum) – Nippon Steel Technical Report https://www.nipponsteel.com/en/tech/r... 7. Haneda D-Runway: 100-year durability on stainless steel legs – Nikkei xTECH (Japanese) https://xtech.nikkei.com/atcl/nxt/col... 8. Haneda's fourth runway unveiled to the press (Aug 2010) – Jiji Press (Japanese) https://www.jiji.com/jc/v2?id=2010101... 9. Tokyo International Airport D-Runway – Obayashi Corporation project record (Japanese) https://www.obayashi.co.jp/chronicle/... 10. Haneda D-Runway feature – KAJIMA Digest, December 2010 (Japanese) https://www.kajima.co.jp/news/digest/... 11. D-Runway construction – Concrete Journal (J-STAGE, Japanese) https://www.jstage.jst.go.jp/article/... 12. D-Runway construction project report – Penta-Ocean Construction (Japanese) https://www.penta-ocean.co.jp/125/pdf... 13. Tokyo International Airport (Haneda) Capacity Analysis 2010 – Japan Schedule Coordination https://www.schedule-coordination.jp/... 14. Haneda / Tokyo International Airport – Airport Technology https://www.airport-technology.com/pr... 15. Tokyo Narita Expansion Plan Aims To Increase Annual Slots To 500,000 – Aviation Week https://aviationweek.com/air-transpor... 16. Tokyo's Airports: Is Haneda Out-Recovering Narita? – OAG https://www.oag.com/blog/tokyos-airpo... Figures are rounded and based on the sources above. Cost in US dollars is an approximate conversion at 2010 exchange rates. #HanedaAirport #JapanEngineering #Megaprojects #EngineeringMarvels #Tokyo
