  If you want one of those CP2100B 2MHz active probes, use the coupon code &quot;ActiveProbe&quot; in my store for 15%<br><a href="https://www.eevblog.com/product/cp2100b/">https://www.eevblog.com/product/cp2100b/</a>

  12

• MA

  @martylawson1638 · 5 years ago

  The restive transmission line probe is my favorite way to make a built in high speed test point. &nbsp;Because of cell-phones there are some absolutely TINY coax connectors. &nbsp;Many are less than 2.5mm on a side. &nbsp;Add a series resistor and you&apos;ve got a GHz bandwidth test point for 30-60 cents in &lt; 10mm^2 that securely hooks to the scope with a $5-10 of coax adapters. &nbsp;Easy to AC couple the test point as well, just &quot;tent&quot; a resistor and a cap in series.

  16

• RO

  @robertsundling · 5 years ago

  I’d love to see an automated test rig where that positional current probe is mounted on an automated XY stage and is scanned across an entire PCB to generate an image of where current is flowing.

  46

• DA

  @danielhe8695 · 5 years ago

  Normal people: RTX 3080 Max-Q Review<br>Me: Active Oscilloscope Probes Review

  23

• GR

  @Graham_Wideman · 4 years ago

  <a href="https://www.youtube.com/watch?v=WlSb8hdFtTY&amp;t=470">7:50</a> Dave demonstrates ESD testing on expensive Agilent active probe. :-)

  1

• AF

  @Afrotechmods · 5 years ago

  Great practical demo thanks.

  16

• NI

  @Nik930714 · 5 years ago

  My DP20003 (5.6KV differential probe) was a real life saver when we were developing some equipment that went up do around 2.3KV. I hated that project, because you always needed to be 100% vigilant or you risked killing yourself or damaging the equipment.

  3

• SI

  @SirBunghole · 5 years ago

  Mr Wu&apos;s differential probe!

  5

• KE

  @KeritechElectronics · 3 years ago

  This really opened my eyes to the whole new worlds of higher end probes. I never realized there were so many types of them, and the I-Prober is indeed interesting to see in action.

• MO

  @mohbit3336 · 5 years ago

  Nice explanation dave I appreciate your work i&apos;ve been following your videos for over a year I learned alot from you keep up the great work 👦

  6

• UD

  @udhayakumara4033 · 5 years ago

  Next DIY current probe?

  4

• WA

  @WacKEDmaN · 5 years ago (edited)

  some great info in these 2 vids... thanks Dave.. good job as usual!<br>nice to see im not the only one who pulls out the magnifying glass with SMD stuff!... i need specsavers!
